Application of flotation machine:
Flotation machine is necessary equipment in most of the ore beneficiation processes, which can be used to separate copper, zinc, lead and other nonferrous mental and non-mental minerals. The flotation machine can form a flotation separation loop by itself without any auxiliary equipment in ore beneficiation production line.
Work Principle of Flotation Machine:
When the floatation machine works, the motor drives the impeller to revolve, so the centrifugal effect and negative pressure are produced. On one hand, ample air is absorbed and mixed with mineral slurry, on the other hand, the mixed mineral slurry is mingled with additive, meanwhile, the foams are thinning, the mineral is bounded with foams, and floats up to the surface of mineral slurry and the mineralized foam is formed. The liquid surface can be adjusted with the height of adjustment flashboard, so that the useful foams are scraped with squeegee.
Technical Parameters of flotation machine:
|
Model |
Capacity (t/h) |
Impeller |
Scraper |
Trough size (mm) |
Weight (kg) |
|||
|
Diameter (mm) |
Speed (r/min) |
Motor Power(Kw) |
Speed (r/min) |
Motor Power(Kw) |
||||
|
SF-0.37 |
0.2-0.4 |
300 |
352 |
1.5 |
16 |
1.1 |
700*700*750 |
468 |
|
SF-0.7 |
0.3-0.9 |
350 |
400 |
3 |
16 |
1.1 |
820*900*920 |
805 |
|
SF-1.2 |
0.6-1.2 |
450 |
312 |
5.5 |
16 |
1.1 |
1100*1100*1100 |
1373 |
|
SF-2.8 |
1.0-3.0 |
550 |
268 |
11 |
16 |
1.1 |
1700*1600*1150 |
2138 |
|
SF-4 |
2.0-4.0 |
650 |
268 |
15 |
16 |
1.5 |
2200*2900*1700 |
3000 |
|
SF-8 |
4.0-8.0 |
760 |
191 |
30 |
16 |
1.5 |
2200*2900*1700 |
4129 |
|
SF-10 |
5.0-10 |
760 |
191 |
30 |
16 |
1.5 |
2200*2900*1700 |
4486 |
|
SF-20 |
5.0-20 |
760 |
191 |
30*2 |
16 |
1.5 |
2850*3800*2000 |
9828 |
