Mining Equipment

Magnetic Separator

Feeding size:0-3mm
Capacity: 10-280TPH
Power:1.5-11kw
Applied material: Iron ore, hematite, magnetite, limonite, calciner, ilmenite, magnetite, copper ore, gold ore, coal, quartz, etc.
Product description: Product description: Magnetic separator is suitable for wet magnetic separation of magnetite, pyrite, calcined ore, ilmenite and other materials with a particle size of less than 3mm.
INQUIRY EMAIL

Application of Magnetic separator

magnetic separator

Magnetic separator is a continuous automatic iron removal magnetic separation equipment from dry power. It s inner adopts unique magnetic circuit design, it make the high-performance permanent magnet king NdFeB materials as the magnetic source, strong magnetic field, big attraction force, high iron removal rate, has the advantages of three maintenance, energy conservation, safe and reliable operation, feed quantity can be adjusted, used for different particles requirements. The magnetic separator is widely used in abrasives, refractories, nonmetal beneficiation, carbon black, grain, feed, chemicals and other industries.

magnetic separator structure

magnetic separator working

Technical Parameters of Magnetic separator

Model	Drum diameter mm	Drum length mm	Rotary speed (r/min)	Feeding Granularity(mm)	Capacity (t/h)	Power (Kw)
CTB6012	600	1200	<35	2-0	10-20	1.5
CTB6018	600	1800	<35	2-0	15-30	2.2
CTB7518	750	1800	<35	2-0	20-45	2.2
CTB9018	900	1800	<35	3-0	40-60	3
CTB9021	900	2100	<35	3-0	45-60	3
CTB9024	900	2400	<28	3-0	45-70	4
CTB1018	1050	1800	<20	3-0	50-75	5.5
CTB1021	1050	2100	<20	3-0	50-100	5.5
CTB1024	1050	2400	<20	3-0	60-120	5.5
CTB1218	1200	1800	<18	3-0	80-140	5.5
CTB1224	1200	2400	<18	3-0	85-180	7.5
CTB1230	1200	3000	<18	3-0	100-180	7.5
CTB1530	1500	3000	<14	3-0	170-280	11
