Applicationof Raymond Mill:
Raymond mill is high efficiency and closed-cyclic fine power grinding machinery. It is used for grinding materials in the fields of building materials, mining, metallurgy and chemical industry. Raymond mill is applicable to the grinding and processing of more than 280 kinds of non-flammable and non-explosive materials with hardness less than 7 and humidity less than 6% in mining, construction, chemical industry and metallurgy, such as Gypsum, talc, calcite, limestone, marble, feldspar, dolomite, barite, kaolin, granite, medical stone, bauxite, iron oxide red, iron ore and so on. The fineness of the finished product can be adjusted from 250 to 325mesh according to requirements. Especial condition, the super-fine mill can realize the 800-1000 mesh fineness. Through the function of separator and blower, Raymond mill can meet different customers demand.
Featuresof Raymond Mill:
1. Three-dimensional structure, small footprint, complete and strong, from raw materials to finished power sub-block self-contained production system independent.
2. Fineness of finished power evenly through screening rate of 99%, which is difficult for other milling equipment available.
3. Transmission device and pulley with sealed gear box, transmission smooth, reliable operation.
4. Important parts are made of high quality steel, wear resistant parts are high-performance materials, machine has high wear resistance and high reliability
5. The electrical system is centralized control, it is easy for operation and maintenance.
Technical Parametersof Raymond Mill:
|
Model
|
Max.Feeding Size (mm) |
Final Granularity (mm) |
Shift capacity (t) |
Central shaft rotary speed |
Ring inner diameter (mm) |
Ring height (mm) |
Host power (mm) |
Fan power (Kw) |
Analyzer power |
Analyzer |
|
3R1410 |
5-8 |
0.125-0.044 |
1-10 |
280 |
Ø405 |
Ø140 |
100 |
7.5 |
5.5 |
1.1 |
|
3R1815 |
15 |
0.125-0.044 |
1-15 |
200 |
Ø550 |
Ø180 |
150 |
11 |
7.5 |
1.5 |
|
3R2615 |
20 |
0.125-0.044 |
2-25 |
165 |
Ø780 |
Ø260 |
150 |
18.5 |
15 |
2.2 |
|
3R2714 |
20 |
0.125-0.044 |
3-28 |
165 |
Ø830 |
Ø270 |
150 |
18.5 |
15 |
2.2 |
|
4R3016 |
15-25 |
0.125-0.044 |
3-36 |
152 |
Ø910 |
Ø300 |
160 |
30 |
22 |
4 |
|
4R3216 |
15-25 |
0.125-0.044 |
3-38 |
130 |
Ø970 |
Ø320 |
160 |
37 |
30 |
5.5 |
|
5R4119 |
15-30 |
0.125-0.044 |
6-66 |
103 |
Ø1280 |
Ø410 |
190 |
75 |
75 |
7.5 |
|
6R4427 |
15-35 |
0.125-0.044 |
9-176 |
100 |
Ø1600 |
Ø440 |
270 |
132 |
132 |
11 |
