Stone Crushing Machine

Spring Cone Crusher

Max Feeding size: 35-300 mm
Power: 30-280 kw
Capacity:40-1000 TPH
Applied material: marble,granite, quartz, pebble,iron ore, talcum, fluorite,gypsum,etc
Product description: Product description: Spring Cone crusher is suitable for secondary crushing rocks with compressive strength of 320 MPa. It widely used in mining, metallurgy, construction, highway, railway, chemistry
INQUIRY EMAIL

spring cone crusher in workshop

Main Function ofSpring Cone Crusher

spring cone crusher application

Spring Cone Crusher is suitable for crushing all kinds of ores and rocks above medium hardness. It has the features of reliable structure, high productivity, easy adjustment and economical operation etc. The spring system acts as an overload protection system that allows iron to pass through the crushing chamber without damaging the crusher. It uses consistent grease or water for sealing, which separates crushed particles and lubricating oil, and ensure reliable work. The types of crushing chamber depend upon the usage of the final products. The standard type is applied to medium crushing; The medium type is fit for medium and fine crushing; The short head type is fit for fine crushing.

spring cone crusher structure

Featuresof Spring Cone Crusher

1. Between-layer pressing crushing and better finished product shape

2. Hydraulic adjustment, hydraulic cavity clearing

3. Easy to operate and maintain

4. PLC control, high degree of automation

5. Standard Replacement Parts

Technical parameterof Spring Cone Crusher

Model			Diameter of Cone (mm)	Max.charge granularity (mm)	Width of discharge part (mm)	Capacity (t/h)	Motor power (kw)	The swing frequency of main shaft(r/min)	Weight （t）	Dimension (L×W×H)(mm)
PYB	600	600		65	12-25	40	30	356	5	2234×1370×1675
PYD	600	600		35	3-13	12-23	30	356	5.5	2234×1370×1675
PYB	900	900		115	15-50	50-90	55	333	11.2	2692×1640×2350
PYZ				60	5-20	20-65			11.2	2692×1640×2350
PYD				50	3-13	15-50			11.3	2692×1640×2350
PYB	1200	1200		145	20-50	110-168	110	300	24.7	2790×1878×2844
PYZ				100	8-25	42-135			25	2790×1878×2844
PYD				50	3-15	18-105			25.3	2790×1878×2844
PYB	1750	1750		215	25-50	280-480	160	245	50.3	3910×2894×3809
PYZ				185	10-30	115-320			50.3	3910×2894×3809
PYD				85	5-13	75-230			50.2	3910×2894×3809
PYB	2200	2200		300	30-60	59-1000	280-260	220	80	4622×3302×4470
PYZ				230	10-30	200-580			80	4622×3302×4470
PYD				100	5-15	120-340			81.4	4622×3302×4470
