Hydraulic Cone Crusher

Main function of Hydraulic Cone Crusher

HP Series of highly efficient Hydraulic Cone Crusher is a world-level cone crusher introduced with the up-to-the-minute technology of Germany. The HP Hydraulic Cone Crusher not only improves the production capacity and crushing efficiency, but also widens applying area, which can break stones from limestone to basalt hardness range. It has a great crushing performance in the work of medium-size crushing, fine crushing and super fine crushing. The  HP Hydraulic Cone Crusher is the improved type of spring cone crusher and can be used to replace ordinary hydraulic cone crusher in the field of mining and construction. It is the most ideal equipment for large stone crushing factory and mining industry.

Operating principle of Hydraulic Cone Crusher:

The working parts are two cutter heads, also called cones; one is fixed cone ( also called outer cone), the other one is movable cone ( also called inner cone. The outer cone is fixed, which is one part of frame; the movable cone is plugged freely in the eccentric bush, so the central axis between the fixed cone and the movable cone intersects and forms into a bevel. When rotating, the movable cone rotates along the inner surface of the fixed cone. The place that the movable cone pressed against the fixed cone becomes the crushing cavity, where the materials is pressed, impacted and bent by the movable cone. The place that the movable moves away from the fixed cone becomes the discharging open, where the crushed materials is discharged out under the role of gravity, and the materials are sent from the feed open.

Feature of the Hydraulic Cone Crusher

1. High crushing ratio and production efficiency.

2. Less spare part consumption and low operation cost.

3. Between-layer pressuring crushing and better finished product shape.

4. Hydraulic protection and hydraulic cavity clearing, high automatization and less stopping production and repairing time.

5. Thin oil lubrication makes the life time increased.

6. Various crushing cavity.

7. Easy maintenance and operation.

8. The crusher can provide customers larger capacity, better product shape, and easy operation.

Technical parameter of Hydraulic Cone Crusher

Pre-sale service

Providing product modelschoosing, technical guidedue to customers requirement

On-purchase service

Providing some documentsneeded for your customsclearance, like commercialinvoice, packing list,certificate of origin etc;

After-sales Service

Installation, debugging, operators training,If needed,we will send engineers to your site to solve your problems.
